Dino-Lite Edge Digital USB Microscope AF4115ZT
Dino-Lite Edge Digital USB Microscope AF4115ZT
Dino-Lite Edge Digital USB Microscope AF4115ZT
Dino-Lite Edge Digital USB Microscope AF4115ZT

Edge Digital USB Microscope AF4115ZT

€569,00 Incl. tax

Product is available!

+ -
Add to cart Add to wishlist
Article number: AF4115ZT
Availability: In stock (1)
Delivery time: Ordered today before 17:00, delivered tomorrow.

The Dino-Lite AF4115ZT is part of Universal series and connects to your device via USB. The AF4115ZT is Wireless-ready, but requires the WF-20 WiFi Streamer to make it a fully wireless solution.

The main features of the AF4115ZT are:

  • Wireless-ready, requires the WF-20 adapter (optional)
  • 1.3MP EDGE SENSOR
  • 20-220x magnification
  • Integrated Polarizer (anti-reflection)
  • Flexible LED Control (FLC)

Specifications

Lighting

  • Light/ LED type: White
  • Number of LEDs: 8
  • LED on/off switchable: Yes
  • Infrared filter: IR cut-filter >650 nm
  • Diffuser available: Yes (N3C-D included)
  • Polarizer: Yes, linear

Optics

  • Magnification: 20-220x
  • Macro zoom: No
  • Working distance: Standard
  • Lens type: Glass with anti-reflection coating

Sensor

  • Sensor type: CMOS
  • Resolution: 1.3 Megapixel (1280x1024)
  • Maximum frame rate: 30 fps

Compatibility

  • Interface: USB 2.0
  • Operating system: Windows 7, 8 & 10, MacOS 10.12 and up
  • Included software: DinoCapture 2.0 (Windows), DinoXcope (Mac OS, no EDOF, EDR)
  • WiFi: Wireless-ready, requires the WF-20 adapter (optional)
  • Supported image formats (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
  • Supported video formats (Windows): WMV, FLV, SWF
  • Supported image formats (MacOS): JPEG, PNG
  • Supported video formats (MacOS): MOV
  • Imaging standards: DirectShow, UVC

Housing

  • Housing material: Composite/plastic housing
  • Magnification lock: Yes
  • Dimensions: 11.4cm (L) x 3.3cm (D)
  • Weight: 111g
  • Cable length: 1.8m



Contents:

  1. Microscope,
  2. Carry pouch,
  3. Software CD,
  4. Calibration target,
  5. User manual,
  6. N3C-O- Open cap, N3C-C- Closed cap, N3C-D- Diffuser cap, N3C-Extension cap, N3C-L- Long cap, N3C-S- Side light cap
  7. 2 years European warranty
