The Axion Compact XG thermal imaging devices use a new approach to image optimisation depending on the purposes and conditions of observation and provide high-quality rendering of both target objects and background. Three levels of signal amplification in combination with a connected smoothing filter and fine brightness and contrast adjustments give the observer great opportunities for long-range detection of the animal under different weather and temperature conditions.
High-quality reinforced magnesium alloy housing
Axion is designed for constant, often hard use. A magnesium alloy housing is light and strong at the same time. The housing reliably protects the internal components of a thermal imaging device from shocks, drops, moisture, heat or cold. At the same time, a metal housing effectively removes the heat from electronics, minimizes image noise and increases consistency of the device operation during long-term observation.
Extended battery life. Up to 11 hours on a single charge
A high-capacity APS5 rechargeable battery provides up to 11 hours of continuous operation of the thermal imaging device on a single charge. The battery is removed from a battery housing and replaced with a new one in seconds. The battery is charged in a special charger or inside the device from a PC, household power system or power bank via USB-C. The same sources are used for external power supply of a thermal imaging device.
Improved Wi-Fi connectivity with 2.4 / 5 GHz waveband support
In Axion Compact XQ thermal imagers, the standard smartphone connection frequency range via a 2.4 GHz WiFi channel is complemented with an effective 5 GHz range. The 5 GHz connection offers better bandwidth, a faster data transfer rate, noise immunity and improved connection stability, resulting in more productive and easier operation of the thermal imager with a smartphone.
Fast aperture lens
Germanium F35/1.0 lens features high infrared transmission in the LWIR range. Due to the high precision manufacturing of the optical elements of the lens, the image generated by the Axion Compact XQ thermal imaging device sensor is distinguished for its clarity and detailing.
Long-distance laser rangefinder
Understanding the target distance is an essential factor in making the right decisions. A built-in laser rangefinder with a range of up to 1 kilometre allows you to measure distances in single measurements and continuous scanning modes with an accuracy of ± 1 meters for quick and error-free assessment of the situation.
Highly-sensitive European-made Lynred sensor
The Axion Compact XQ35 is equipped with a European Lynred sensor with a resolution of 384x288 pixels (pixel size 17 microns), the axion 2 XG35 has 640x480 pixels. which qualitatively captures a useful signal under difficult observation conditions, such as rain, fog and high atmospheric humidity at the observation site.
Built-in photo and video recorder. Free 16 GB cloud space
The Axion Compact XQ has a built-in video recorder. The internal memory of the Axion 2 XQ can store hours of video and tens of thousands of photos. One touch of a button is enough to take a photo of an interesting scene or start recording video. The footage is copied to a computer hard drive via a USB-C port. The Axion Compact XQ owner has a free 16 GB disk space for storing photos and videos captured with the device in the Pulsar cloud storage. Simply install the Stream Vision 2 mobile application, log in and connect the device with a smartphone via WiFi.
1750 m detection range
A powerful F35/1.0 objective lens combined with a 640x480@12µm highly-sensitive thermal imaging sensor provides exceptional detection capabilities. A standard 1.8m tall object can be detected up to 1750 m away in complete darkness.
| Product weight | 350 g |
| Microbolometer | 640x480 pix. @ 12 µm |
| NETD value | <40mK |
| Type display/ resolution | AMOLED HD 640x400 |
| Objective lens | F35/ 1.0 |
| Frame rate | 50 Hz |
| Magnification | 2,5 - 20x |
| Detection distance | 1750 m |
| Photo / video recording | Yes |
| Photo/ video resolution | 960x600 |
| Wi-Fi | Yes |
| Stream Vision | Yes |
| Type of battery | APS 5 Li-ion Battery Pack |
